Electroplated diamond cutting discs have good performance on the sharpness and lower heat. They are more suitable
for dry cutting. They can be used for cutting many hard and abrasive materials such as marble, granite, thermosetting
plastics, GRP, pre-sintered and pre-fired (green) materials, electro carbons, graphite, soft ferrites, farinaceous products,
pc boards, etc.
Generally speaking, there are such kind of types as following,
|
¡°U¡± shape slot |
Key hole slot |
Segmented rim cutting discs
suitable for cutting marble, granite and abrasive materials |
We can make it according to customers¡¯ designs and specifications.
¢±Segmented rim diamond cutting blade
|
ORDER NO |
OUTSIDE DIAMETER |
CORE THICKNESS |
HOLE |
DIAMOND |
|
INCH |
MM |
MM |
DIAMETER |
RETURN |
|
|
SPB1 |
|
SPB1-1/2 |
|
SPB2 |
|
SPB2-1/2 |
|
SPB3 |
|
SPB3-1/2 |
|
SPB4 |
|
1"
1-1/2"
2"
2-1/2"
3"
3-1/2"
4" |
25
30
50
65
75
80
100 |
0.6-1.2
0.6-1.2
0.6-1.2
0.6-1.2
0.6-1.2
0.6-1.2
1.3-1.5 |
SPECIFY |
SPECIFY |
|
SPB5 |
|
SPB6 |
|
SPB7 |
|
SPB8 |
|
SPB10 |
|
5"
6"
7"
8"
9"
10" |
125
150
180
200
230
250 |
1.3-1.5
1.3-1.5
1.4-1.6
1.6-2.2
1.6-2.2
1.8-2.5 |
SPECIFY |
SPECIFY |
|
|
12"
14"
16"
18" |
300
350
400
450 |
1.8-3.0
1.8-3.0
1.8-3.0
2.0-3.5 |
SPECIFY |
SPECIFY |
¡ï"SPB" means SLOTTED/SEGMENT RIM PLATED BLADE
|
|
Continuous rim cutting discs
cutting more smoothly on fiberglass, plastic, ceramic tiles & etc. |
|
|
Continuous rim with wear bars
wear bar is also named as pads or protection tips sometimes |
¢²Continuous rim diamond cutting blade
USB01 |
USB02 |
USB03  |
USB04 |
USB05  |
USB06 |
USB07 |
USB08 |
|
|
OUTSIDE DIAMETER |
CORE THICKNESS |
HOLE |
DIAMOND |
| |
INCH |
MM |
MM |
DIAMETER |
RETURN |
|
USB1 |
|
USB1-1/2 |
|
USB2 |
|
USB2-1/2 |
|
USB3 |
|
USB3-1/2 |
|
USB4 |
|
1"
1-1/2"
2"
2-1/2"
3"
3-1/2"
4" |
25
30
50
65
75
80
100 |
0.6-1.2
0.6-1.2
0.6-1.2
0.6-1.2
0.6-1.2
0.6-1.2
1.3-1.5 |
SPECIFY |
SPECIFY |
|
USB5 |
|
USB6 |
|
USB7 |
|
USB8 |
|
USB10 |
|
5"
6"
7"
8"
9"
10" |
125
150
180
200
230
250 |
1.3-1.5
1.3-1.5
1.4-1.6
1.6-2.2
1.6-2.2
1.8-2.5 |
SPECIFY |
SPECIFY |
|
|
12"
14"
16"
18" |
300
350
400
450 |
1.8-3.0
1.8-3.0
1.8-3.0
2.0-3.5 |
SPECIFY |
SPECIFY |
¡ï"USB" means UNSLOTTED/CONTINUOUS RIM PLATED BLADE
¢³Electroplated concave diamond blades
Application for cutting sunk hole of slab or special curve edge where traditional diamond blade can not work.
|
ORDER NO |
OUTSIDE DIAMETER |
CORE THICKNESS |
HOLE |
DIAMOND |
| |
INCH |
MM |
MM |
DIAMETER |
RETURN |
|
|
5"
6"
7"
8" |
125
150
180
200 |
1.6-1.8
1.6-1.8
1.6-1.8
1.6-1.8 |
SPECIFY |
SPECIFY |
¡ï"CSB" means CONCAVE PLATED BLADE
|
